Mori Seiki NH5000dcg - Horizontal Machining Centers

Share Machine

Specifications Print Specs

Model: NH5000dcg

Year: 2013

Stock #: 13818 Sold

Type: Horizontal Machining Centers

Manufacturer: Used Mori Seiki Machines

Highlights:
Hydraulic Clamping Thru Pallet
Hi Pressure Coolant Thru Spindle
15,000 rpm | HSK 100 | 54 Station ATC

Mori Seiki NH5000 DCG CNC Horizontal Machining Center For Sale 2013

Equipped With:

- Chip Blaster
- Transformer
- Chip Conveyor
- Coolant Tank & Pump
- Hydraulic Clamping Thru Pallet
- High Pressure Coolant Thru Spindle
- Dual Ball Screws (X/Z Axes)

Machine Specifications

Inch

Metric

Machine Specifications:

Year

2013

# Axis

Pallet Length

19.7"

Pallet Width

19.7"

Pallet Load Capacity

1,100 pounds

Pallet Indexing (B-Axis)

0.001°

X-Axis Travel

28.7"

Y-Axis Travel

28.7"

Z-Axis Travel

33.5"

Rapid Traverse Rate (X/Y/Z)

1,969 ipm

Spindle Taper

HSK 100

Spindle Speed

15,000 rpm

Spindle Motor (HP)

40 hp

Tool Changer Capacity

Coolant Through Spindle

yes

Machine Dimensions

182" x 108" x 124"

Machine Weight

29,000 pounds

Equipped With:

- Chip Blaster
- Transformer
- Chip Conveyor
- Coolant Tank & Pump
- Hydraulic Clamping Thru Pallet
- High Pressure Coolant Thru Spindle
- Dual Ball Screws (X/Z Axes)

The Mori Seiki NH5000dcg is an exclusive part of our Horizontal Machining Centers inventory which we own and service. We're the international CNC specialists with the best guarantee in the industry.
