Mori Seiki NT4300DCG/1500 SZ - Lathes (3-Axis or More)

Request Quote
Share Machine
Specifications Print Specs
Model: NT4300DCG/1500 SZ
Year: 2013
Stock #: 15076
Highlights:
Fanuc 31iA CNC Control
B-Axis Milling Head +/-120°
12,000 rpm Milling Spindle
100 Station ATC - CAPTO C6
Renishaw Probing
Lower Turret & Sub Spindle

2013 Mori Seiki NT4300DCG/1500SZ CNC Lathe Mill-Turn For Sale
Machine Specifications
Year
2013
CNC Control
yes
Control Type
Fanuc 31iA
# Axis
9
Swing
28.7"
Turning Diameter
25.9"
Turning Diameter Lower Turret
13.78"
Sub Spindle Motor (HP)
30/25 hp"
Chuck Size
15"
Bar Capacity
3.54"
X Axis Travel
29.53"
X2 Axis Travel
7.68"
Y Axis Travel
8.27"
Z Axis Travel
61.02"
Z2 Axis Travel
60.04"
B Axis Rotation Range
+/- 120°
B Axis Indexing
0.0001°
C1/C2 Axis Index
0.001°
Spindle Speed
4,000 rpm
Main Motor
30 hp
Sub Spindle
yes
Sub Spindle Chuck
15"
Sub Spindle Speed
4,000 rpm
Milling Spindle Taper
Capto C6
Milling Spindle Speed
12,000 rpm
Turret Capacity
10 Stations - Lower Turret
Tailstock
no
Y Axis
yes
Machine Weight
59,000 pounds

Equipped With:

- Fanuc 31iA CNC Control
- Full B Axis Milling Head
- Renishaw Probing (Receiver)
- Scale Feedback on X
- Chip Blaster High Pressure Coolant Unit
- Chip Conveyor
- Tool Presetter
- 100 Station Automatic Tool Changer ATC (Option)
- Assorted Capto Tools
- Hobbing Function Software ($$ OPTION)
- Transformer
- Chiller

The Mori Seiki NT4300DCG/1500 SZ is an exclusive part of our Lathes (3-Axis or More) inventory which we own and service. We're the international CNC specialists with the best guarantee in the industry.
